Mist Air Shower
Kondaas Airtech’s Mist Air Shower goes beyond conventional decontamination — combining the power of ultra-clean filtered air with advanced misting technology for a comprehensive three-in-one solution. Air is forced through HEPA filters with 99.99% efficiency against particles as small as 0.3 microns, with jets reaching velocities of 23 m/s for thorough and efficient particle scrubbing. The integrated misting system then atomizes and evenly distributes liquid throughout the chamber for complete surface coverage.
- Triple Action Performance — Simultaneously eliminates particles, disinfects, and deodorizes in a single cycle
- Even Mist Distribution — Liquid is atomized and sprayed uniformly throughout the entire air shower chamber for consistent coverage
- HEPA Filtration — 99.99% efficiency against particles as small as 0.3 microns for ultra-clean airflow
- High-Velocity Air Jets — Air jets at 23 m/s for powerful and thorough particle removal from all surfaces
- Fast Cycle Times — Rapid decontamination cycles minimize wait times without compromising effectiveness
| Model | KAAS-CASM03103-A.B |
| Particle Efficiency | Above 99.99% Efficient On 0.3μm Particles(HEPA) Above 99.999% Efficient On 0.1μm Particles(ULPA)(optional) |
| Pre-filter | Non-woven filter |
| Main filter | HEPA filter / ULPA filter(optional) |
| Nozzle Qty. | 20pcs |
| Spray nozzle Qty. | 6pcs |
| Air velocity (m/s) | About 23 |
| Air volume (CMM) | About 19.5 |
| Air change (time/hour) | 487 |
| Base | SUS304 |
| Construction | Cold-rolled steel with baked painting/SUS304(optional) |
| Color | Ivory pearl white(optional) |
| Power supply | AC 3Φ220 50/60Hz |
| Inductive control | Photo-electric sensor |
| LED illumination(W) | 10×1 |
| Spray system(optional) | Spray nozzle SUS304 tank air compressor 5~7kg/cm2 |
