Cleanroom Air Shower (Turbo DC Blower)
The Kondaas Airtech Turbo DC Blower Air Shower delivers exceptional energy efficiency while producing ultra-clean air. Powered by high-performance blowers, air is forced through HEPA filters with 99.99% efficiency against particles as small as 0.3 microns, with air jets reaching velocities of 23 m/s for powerful and thorough particle removal.
- High Static Pressure DC Blower – Compact and powerful, a single unit delivers outstanding decontamination performance with minimal power consumption
- 30% Energy Savings – Significantly reduces electricity consumption compared to traditional air showers by minimizing the number of motors required
- Integrated Programming System – Easily customizable program settings that can be fine-tuned and modified to suit your specific operational needs
- Intelligent Control System – Modular control panel with smart programming ensures stable, consistent, and reliable performance at all times
- Energy-Saving LED Lighting – Clear power indicators and graphical displays make operation simple, intuitive, and energy efficient
- Built-In Full-Length Mirrors – Dual side mirrors allow personnel to inspect and tidy their cleanroom overalls before completing entry
| Model | KAAS-CAS3103-A | KAAS-CAS3103-A.B |
| Dimension (WxDxH)(mm) | 800x1200x1000 | 800x1200x1500 |
| Circulation (hour) | 658 times | 487 times |
| Nozzles Qty | 18 | 20 |
| Air Velocity (m/s) | ≥23 | |
| Air Volume (CMM) | 17.5 | 19.5 |
| Electrical | AC 3Φ220V 50/60Hz | |
| Pre-Filter | Non-woven filter | |
| Particle Efficiency | Above 99.99% Efficient On 0.3μm Particles | |
| Operation switch | Single-chip microcontroller | |
| Base | Base pedal stainless steel SUS304 | |
| Construction | Cold-rolled steel with baked painting | Stainless steel SUS304(optional) |
| Color | Ivory, pearl white(optional) | |
| Sensor | Photoelectric sensor switch | |
| LED light | 10W x1pc | |
| Interlocking Action | Both doors are interlocked. When one door is opened, the other door is locked. In case of power failure, the door locks are automatically released for safe personnel exit. | |
| Optional | Voice guidance system, sheet shutter door, auto door |
